The U.S. Department of Commerce announces $1.4 billion in new awards under the CHIPS National Advanced Packaging Manufacturing Program to establish a domestic ecosystem for advanced chip design, fabrication, and packaging.
Design for Testability (DFT) plays a critical role in ensuring the safety and reliability of complex chips for sectors like autonomous vehicles and defense systems.
Vijayaprabhuvel Rajavel, a Technical Architect at HCL America, highlights the importance of DFT in the context of the CHIPS Act and the shift toward localized manufacturing and packaging.
DFT enables data continuity and faster yield learning, crucial for safety-critical domains such as defense and automotive.
In complex ASIC designs for chiplets and autonomous systems, DFT requires modular, RTL-aware approaches to ensure fault coverage and traceability.
Early integration of DFT in high-risk applications like self-driving vehicles is essential for meeting safety standards and production timelines.
Improving scan coverage in complex designs involves tailored strategies, wrapper insertion, and automating DRC cleanup.
Balancing thorough testing with minimizing power consumption in semiconductor designs requires toggle-aware pattern generation and power domain analysis.
Engineers need strong digital design, testing, and data skills to adapt to the changing landscape of DFT, especially with the influence of AI/ML.
Machine learning is shaping the future of DFT by optimizing test flows, predictive pattern generation, and integrating AI automation for smarter and more adaptable testing.
ML accelerates DFT through predictive pattern generation, adaptive test flow, and generative AI automation, enabling intelligent, self-learning test systems for advanced nodes and heterogeneous integration.
